Description
The Wilwood Narrow Superlite 6R Front Brake Kit (part number 140-10815-DR) is configured with 12.88 in Drilled & Slotted Rotors - Red Powder Coat Calipers. Application: 1962-1972 CDP B & E Body-Drum.
The radial-mount caliper arrangement uses a dedicated bracket to establish caliper position over the rotor. Bracket geometry and rotor offset are therefore part of the fitment specification. The rotor configuration and caliper finish shown here identify this specific part number. Match the required axle, spindle, mounting arrangement, and any listed offset to the vehicle’s installed components.
Technical details
- Selected configuration: 12.88 in Drilled & Slotted Rotors - Red Powder Coat Calipers.
- Application: 1962-1972 CDP B & E Body-Drum.
- Configuration: Hub Kit.
- Caliper series: Forged Narrow Superlite 6R.
- Pistons per caliper: 6.
- Piston material: Stainless.
- Caliper mounting: Radial.
- Pad shape: 7416.
- Pad compound: BP-10.
- Listed piston bore sizes: 1.75 / 1.25 / 1.25 in.
- Caliper finish: Red Powder Coat.
- Rotor material: Spec-37 Iron.
- Rotor surface finish: Black Electro Coat.
- Rotor dimensions: 12.88 in diameter × 1.10 in thickness.
- Caliper mounting arrangement: Radial.
Cataloged vehicle applications
- 1970-1972 Dodge Challenger — Base
- 1970-1971 Dodge Challenger — R/T
- 1972 Dodge Challenger — Rallye
- 1970 Dodge Challenger — T/A
- 1969-1971 Dodge Charger — 500
- 1966-1972 Dodge Charger — Base
- 1967-1971 Dodge Charger — R/T
- 1971-1972 Dodge Charger — Special Edition
- 1971 Dodge Charger — Super Bee
- 1966-1970 Dodge Coronet — 440
- 1966-1970 Dodge Coronet — 500
- 1966,1970-1972 Dodge Coronet — Base
- 1971 Dodge Coronet — Brougham
- 1971-1972 Dodge Coronet — Crestwood
- 1971-1972 Dodge Coronet — Custom
- 1966-1970 Dodge Coronet — Deluxe
- 1967-1970 Dodge Coronet — R/T
- 1968-1970 Dodge Coronet — Super Bee
- 1968-1972 Plymouth Road Runner — Base
Selection and installation: Wilwood lists a potential minimum wheel diameter of 17 inches. Actual clearance depends on wheel barrel and spoke shape; verify the wheel-clearance dimensions for this kit.
