Description
The Wilwood Narrow Superlite 6R Front Brake Kit (part number 140-10752-D) is configured with 12.88 in Drilled & Slotted Rotors - Black Calipers. Application: 2008 Toyota Matrix.
The radial-mount caliper arrangement uses a dedicated bracket to establish caliper position over the rotor. Bracket geometry and rotor offset are therefore part of the fitment specification. The application-specific design accounts for original-equipment master-cylinder output and ABS operation where fitted. Retain the specified vehicle and brake configuration when evaluating compatibility. The rotor configuration and caliper finish shown here identify this specific part number. Match the required axle, spindle, mounting arrangement, and any listed offset to the vehicle’s installed components.
Technical details
- Selected configuration: 12.88 in Drilled & Slotted Rotors - Black Calipers.
- Application: 2008 Toyota Matrix.
- Configuration: Hat Kit.
- Caliper series: Forged Narrow Superlite 6R.
- Pistons per caliper: 6.
- Piston material: Stainless.
- Caliper mounting: Radial.
- Pad shape: 7416.
- Pad compound: BP-10.
- Listed piston bore sizes: 1.62 / 1.12 / 1.12 in.
Cataloged vehicle applications
- 2009-2011 Toyota Matrix — Base
- 2009-2011 Toyota Matrix — S
- 2009-2010 Toyota Matrix — XRS
Selection and installation: Wilwood lists a potential minimum wheel diameter of 17 inches. Actual clearance depends on wheel barrel and spoke shape; verify the wheel-clearance dimensions for this kit.
