Description
The Wilwood Forged Dynalite Front Brake Kit (part number 140-11275-D) is configured with 12.19 in Drilled & Slotted Rotors - Black Calipers. Application: 1982-1992 Chevrolet Camaro / 1982-1992 Pontiac Firebird.
The rotor configuration and caliper finish shown here identify this specific part number. Match the required axle, spindle, mounting arrangement, and any listed offset to the vehicle’s installed components.
Technical details
- Selected configuration: 12.19 in Drilled & Slotted Rotors - Black Calipers.
- Application: 1982-1992 Chevrolet Camaro / 1982-1992 Pontiac Firebird.
- Caliper series: Forged Dynalite Internal.
- Pistons per caliper: 4.
- Piston material: Stainless.
- Caliper mounting: Lug.
- Pad shape: 7112.
- Pad compound: BP-10.
- Listed piston bore sizes: 1.75 / 1.75 in.
Cataloged vehicle applications
- 1988 Chevrolet Camaro — Base
- 1982-1986 Chevrolet Camaro — Berlinetta
- 1985-1990 Chevrolet Camaro — Iroc-Z
- 1987 Chevrolet Camaro — LT
- 1989-1992 Chevrolet Camaro — RS
- 1992 Chevrolet Camaro — RS Heritage Edition
- 1982-1987 Chevrolet Camaro — Sport
- 1982-1987,1991-1992 Chevrolet Camaro — Z28
- 1992 Chevrolet Camaro — Z28 Heritage Edition
- 1982 Chevrolet Camaro — Z28 Indianapolis 500 Pace Car
- 1982-1992 Pontiac Firebird — Base
- 1989-1992 Pontiac Firebird — Formula
- 1982-1986 Pontiac Firebird — S/E
- 1982-1992 Pontiac Firebird — Trans Am
- 1989-1992 Pontiac Firebird — Trans Am GTA
- 1989 Pontiac Firebird — Trans Am GTA SE
Selection and installation: Wilwood lists a potential minimum wheel diameter of 15 inches. Actual clearance depends on wheel barrel and spoke shape; verify the wheel-clearance dimensions for this kit.
