Description
Fits
- Cadillac ATS; Sedan, Coupe, 2WD
Fitment Requirements
- Drivetrain: 2WD
Recommended when you want: Height adjustment plus control over rebound damping so ride and chassis response can be fine-tuned.
Product Features
- Seamless application-specific ride-height adjustment
- 16-click adjustable rebound damping
- Factory-recommended damper setting provides a repeatable baseline
- Composite spring perch and galvanized steel strut construction
Application Specifications
| Ride-height range | Front: 25-50 mm / Rear: 10-40 mm |
| Spring rates | Front: 285 lb/in / Rear: 570 lb/in |
Additional Fitment Notes
- For vehicles equipped with electronic damping, the electronic damping control needs to be deactivated. Deactivation kit KW Part-no. 68510431
Compare ST Coilover Families
| System | Height | Rebound | Compression | Top Mounts |
|---|---|---|---|---|
| ST X | Yes | Fixed | — | — |
| ST XA | Yes | 16-click rebound | — | — |
| ST XTA | Yes | 16-click rebound | — | Top mounts* |
| ST XTA Plus 3 | Yes | 16-click rebound | 24-click high + low speed | Top mounts* |
*Top-mount design and adjustability are application-dependent. Confirm the exact kit contents for your vehicle.
ST Part Number: 18263004
