Description
Fits
- 1998–2001 Audi A4 (8D/B5) Sedan, Wagon 2WD VIN# from 8D*X200000 up
Fitment Requirements
- Drivetrain: 2WD
Recommended when you want: Height adjustment with a complete ST spring-and-damper package and no damping adjustments to manage.
Product Features
- Seamless application-specific ride-height adjustment
- Fixed damping calibrated for the application
- Composite spring perch designed to maintain smooth height adjustment
- Galvanized steel strut construction with dust and sealing protection
Application Specifications
| Ride-height range | Front: 40-70 mm / Rear: 40-70 mm |
| Spring rates | Front: 690 lb/in / Rear: P lb/in |
Additional Fitment Notes
- Excluding all models with 4 wheel drive
- Only for models up to chassis number 8D*X 199999
- Because of the construction of the car the damping adjustment can only made when the damper is not mounted. By modifying the interior trim this problem can be avoided.
Compare ST Coilover Families
| System | Height | Rebound | Compression | Top Mounts |
|---|---|---|---|---|
| ST X | Yes | Fixed | — | — |
| ST XA | Yes | 16-click rebound | — | — |
| ST XTA | Yes | 16-click rebound | — | Top mounts* |
| ST XTA Plus 3 | Yes | 16-click rebound | 24-click high + low speed | Top mounts* |
*Top-mount design and adjustability are application-dependent. Confirm the exact kit contents for your vehicle.
ST Part Number: 13210038
