Description
Manley packages these Race Series exhaust valves for Ford 429 around the measurements that matter during cylinder-head setup, rather than treating every valve size as a separate shopping path. The selectable configurations in this family are separated by head diameter, overall length, stem diameter, so the final SKU should be chosen from the dimensional requirements of the build.
For Ford 429, valve diameter changes can alter seat work and chamber/shrouding relationships, while alternate overall lengths can change installed height and rocker geometry.
Key Product Details
- Application: Ford 429
- Manley Series: Race Series
- Valve Position: Exhaust
- Product Family Detail: Severe Duty application focus
- Product Family Detail: Race Series application focus
- Manufacturer Part Numbers: Vary by selected configuration (4 SKUs in this parent family)
Available Configurations
This parent listing contains multiple selectable Manley SKUs. Choose the configuration that matches the measured engine or cylinder-head specification.
- Head Diameter: 1.880in, 1.760in
- Overall Length: 5.170in, 5.070in, 5.167in, 5.067in
- Stem Diameter: 0.3415in
Package Quantity
Set of 8 valves. The selected configuration is supplied as a 8-piece valve package. This quantity applies to the selected Manley SKU family shown on this product page.
Selection & Fitment Notes
Before purchase, compare the selected valve dimensions with your head manufacturer or engine builder’s specification, including stem diameter, valve length, seat diameter, and keeper arrangement.
Professional engine assembly and measurement are recommended. Product specifications should be confirmed against the selected Manley part number and the requirements of the exact engine build.
