Description
This Race Series exhaust valve listing is organized specifically for Ford 289, with the available dimensions presented as selectable configurations for easier cylinder-head planning. The selectable configurations in this family are separated by head diameter, overall length, stem diameter, so the final SKU should be chosen from the dimensional requirements of the build.
The correct Ford 289 valve is the one that matches the finished head. Stem clearance, seat contact, installed height, spring package, and keeper location should all be checked during assembly.
Key Product Details
- Application: Ford 289
- Manley Series: Race Series
- Valve Position: Exhaust
- Product Family Detail: Race Series application focus
- Manufacturer Part Numbers: Vary by selected configuration (2 SKUs in this parent family)
Available Configurations
This parent listing contains multiple selectable Manley SKUs. Choose the configuration that matches the measured engine or cylinder-head specification.
- Head Diameter: 1.600in, 1.465in
- Overall Length: 4.911in, 5.080in
- Stem Diameter: 0.3415in
Package Quantity
Set of 8 valves. The selected configuration is supplied as a 8-piece valve package. This quantity applies to the selected Manley SKU family shown on this product page.
Selection & Fitment Notes
Use the finished cylinder-head setup as the authority for selection. Oversize valves or alternate lengths may require machining and can affect installed height and valvetrain geometry.
Professional engine assembly and measurement are recommended. Product specifications should be confirmed against the selected Manley part number and the requirements of the exact engine build.
