Description
For a 2009–2017 Audi Q5 (8R | With DCC) being developed beyond stock suspension behavior, KW Street Comfort provides a more deliberate foundation for ride height, body control and tire management.
KW Street Comfort is aimed at drivers who want adjustable ride height and more disciplined chassis control without making maximum firmness the objective. Rebound adjustment lets the final setup be biased toward a more relaxed road ride or tighter body control as the vehicle and wheel/tire package demand. The application-specific calibration is intended to give the chassis a more deliberate response than a one-size-fits-all suspension combination.
Why Choose the KW Street Comfort for This Application?
Choose Street Comfort when road compliance remains a priority. It is aimed at owners who want a lower, more disciplined chassis but do not want a setup whose character is defined primarily by track use.
Key Features
- Ride-height adjustment with a comfort-focused operating window
- Adjustable rebound damping
- Application-specific spring and damper calibration
- Designed for frequent street use and long-distance drivability
Vehicle Fitment
- Make: Audi
- Application: Q5 (8R); with electronic damping (bundle incl. magnetic ride cancellation unit)
- Configuration: all models; all engines
- KW Jobber Model Years: 09-17
- KW Part Number: 18010103
Technical Specifications
- Front Height Adjustment: 30-70 mm (1.2-2.7 in)
- Rear Height Adjustment: 35-75 mm (1.4-3.0 in)
- Front Spring Rate: Progressive-rate spring (KW jobber designation)
- Rear Spring Rate: Progressive-rate spring (KW jobber designation)
Enthusiast Setup Perspective
A good installation should leave enough travel for the road or circuit being used. Chasing maximum lowering at the expense of bump travel can work against the very grip and control this system is intended to provide. For a road-driven car, preserving usable bump travel and sensible alignment is usually more important than using the full available lowering range.
Important KW Fitment Notes
- KW Note 2: Height adjustable front and rear axles (front axle threaded strut housings, rear axle adjustable springs + dampers)
- KW Note 88: Electronic damping control has to be deactivated. Deactivation kit is included in the delivery.
Fitment note: Specifications above are tied to the exact KW part number shown and the application data in the supplied KW jobber sheet. Confirm the vehicle's drivetrain, factory electronic suspension, axle weight and any listed hardware requirements before ordering.
