Description
KW V5 Clubsport targets owners of the 2016–2021 Mercedes-Benz AMG GT (Coupe, Roadster) who want a suspension package selected around the vehicle application rather than a generic spring-and-damper combination.
KW V5 Clubsport represents the most tuning-intensive end of the road-legal Clubsport range, with independent low- and high-speed adjustment for both rebound and compression. It is intended for developed track cars where tire, aero, alignment and load changes justify a wide damper tuning window. The setup should be viewed as a tunable system whose final behavior depends on alignment, tire, ride height and the driver's intended circuit use.
Why Choose the KW V5 Clubsport for This Application?
Choose V5 Clubsport for a highly developed road-legal track car where four-way damping is justified by the rest of the package. This is suspension for iterative setup work, not a fit-and-forget lowering solution.
Key Features
- Low- and high-speed rebound adjustment
- Low- and high-speed compression adjustment
- Motorsport-oriented Clubsport calibration
- Application-specific top-mount and spring configuration where listed
Vehicle Fitment
- Make: Mercedes-Benz
- Application: AMG GT
- Configuration: Coupe, Roadster; incl. GT S, GT C, GT C Edition 50
- KW Jobber Model Years: 16-21
- KW Part Number: 3090125080
Technical Specifications
- Front Height Adjustment: 25-40 mm (1.0-1.6 in)
- Rear Height Adjustment: 30-45 mm (1.2-1.8 in)
- Front Spring Rate: 570 lb/in
- Rear Spring Rate: 400 lb/in
- Top Mount Configuration: Fixed / Fixed
Enthusiast Setup Perspective
The tuning opportunity is greatest when the car has already moved beyond basic cosmetic modification. As grip and braking capability increase, damper control becomes progressively more important to keeping the chassis predictable. After installation, establish ride height and alignment first, then make damper changes in small increments and record them so the effect of each adjustment remains clear.
Important KW Fitment Notes
- KW Note 1: Height adjustable on the front and rear axles (threaded strut housings)
- KW Note 37: For cars which have electronic dampers, make sure they are shut down. Specific electronical damper shut-downs are available from KW. Please check our accessories list
- KW Note 67: Valving is adjusted by adjustment knobs, rebound is only adjustable if the top of the piston rod is accessible. This will depend on the design of the vehicle.
- KW Note 90: Aluminium suspensions struts
- KW Note 98: Clubsport coilover with top mount: with front- and rear axle top mount available
Fitment note: Specifications above are tied to the exact KW part number shown and the application data in the supplied KW jobber sheet. Confirm the vehicle's drivetrain, factory electronic suspension, axle weight and any listed hardware requirements before ordering.
