Description
The HT1 is a twelve-spoke wheel from KONIG’s HyperTrail range for truck, Jeep, and SUV applications. It combines flow-formed construction with a reinforced rear flange and knurled bead seats.
This listing specifies an 18x9 wheel, a +0mm offset, a 5x127 bolt pattern, and Matte Black finish.
Engineering and design
Flow forming applies pressure to the wheel barrel after casting to develop the finished barrel structure. It is a different manufacturing process from producing a fully forged wheel.
Knurled bead seats add texture at the tire-to-wheel interface to help resist tire movement relative to the wheel during demanding acceleration or braking.
A thicker rear flange supports rigidity at the inner wheel edge. Vehicle axle-load requirements must still be checked against the rating of the exact wheel.
Specifications
- Manufacturer part number: H1985127005
- Wheel size: 18x9
- Offset: +0mm
- Bolt pattern: 5x127
- Finish: Matte Black
- Construction: Flow formed
- Center bore: 71.5mm
- Published load rating: 2500 lb per wheel
- Published wheel weight: 27.32 lb
- Bead-seat feature: Knurled
Fitment considerations
Confirm the vehicle hub diameter, correct lug hardware and seating type, brake clearance, tire sizing, and suspension and fender clearance before ordering. Bolt pattern alone does not establish fitment. Hub rings may be needed when the wheel bore is larger than the vehicle hub.
Wheel width and offset work together to determine inner and outer clearance. Check the intended tire and suspension setup as part of the complete fitment.
