Description
The HKS R Type Intercooler Kit provides an application-specific charge-air cooling component. Application: Mazda RX-7 (FD3S).
Design and operation
An intercooler transfers heat from compressed intake air to the surrounding cooling air. Core dimensions, end-tank layout and airflow through the bumper all influence its operation; a larger core dimension alone is not a guaranteed horsepower gain.
Technical details
- Manufacturer part number: 13001-AZ004.
- Configuration: Full Kit / For Factory Turbo
- Application: Mazda RX-7 (FD3S).
- Core size / layout: 600X255.6X103 mm; V system.
Application-specific requirements
- Full Kit (for stock turbine) ※Battery must be changed (38B19R Flat top).
- ※Racing Suction(70020-AZ101) required.
- V-mount layout, For stock turbine, Must be installed with HKS Racing Suction Kit (70020-AZ101), Intercooler core: R-type 600x255.6x103 (mm).
Installation and selection
Check whether the selected part supplies the core only or includes piping. Confirm compatibility with the factory or aftermarket turbo plumbing and any required bumper, duct or sensor changes.
