Description
The HKS GT5565_BB is a standalone ball-bearing turbocharger with a T25 turbine-inlet flange and A/R 0.75 turbine housing. It is a component for a matched turbo installation, not a complete vehicle conversion kit.
Design and operation
The T25 mounting interface and four-bolt turbine outlet define the exhaust-side connections. The compressor housing has a 101.6 mm inlet and 50.8 mm outlet. These dimensions need to be coordinated with the intake and charge piping, while the A/R 0.75 housing must be selected as part of the engine’s turbine and boost-control combination.
Technical details
- Manufacturer part number: 14001-AK065.
- Turbocharger model: GT5565_BB.
- Bearing configuration: ball bearing.
- Turbine-inlet flange: T25.
- Turbine-outlet connection: four-bolt.
- Turbine housing A/R: 0.75.
- Compressor housing inlet / outlet: 101.6 / 50.8 mm.
- Published product weight: 10.3 kg.
Installation and selection
Match the manifold and turbine-outlet pipe to these interfaces. Provide the required lubrication, charge piping, wastegate control and engine calibration for the completed system. Compressor-flow or power-capacity descriptions do not establish a guaranteed engine output.
