Description
The HKS GT Supercharger Pro Kit provides the specified HKS supercharger system or assembly. Application: Honda CR-Z (ZF1).
Design and operation
A centrifugal supercharger is driven mechanically, with its airflow and pressure delivery changing with operating speed. Final performance depends on the pulley combination, charge-air cooling, fuel system and engine calibration, rather than the compressor designation alone.
Technical details
- Manufacturer part number: 12001-AH007.
- Application: Honda CR-Z (ZF1).
Application-specific requirements
- No modification to the engine is necessary if the engine output is increased up to 200ps.(However, it is recommended to use HKS engine upgrade parts for race use.).
- The factory ECU must have the standard data.
- High octane gasoline must be used.
- Since the factory washer tank is removed to install the kit, DENSO Washer Assy (160200-5070) or similar item may be required.
- Average required installation time is 6 to 8 hours.
Installation and selection
Plan engine management, fueling and thermal management for the complete installation. Match the supplied package to the required supporting hardware; a standalone assembly and a vehicle-specific system do not contain the same components.
