Description
The HKS Connecting Rod Set provides the listed connecting-rod set for the specified engine configuration. Application: SR20DET.
Design and operation
Connecting rods must match crankpin dimensions, wrist-pin fitment and the required center-to-center length. A compatible engine-family label does not replace dimensional checks when the engine uses a stroker crankshaft or aftermarket pistons.
Technical details
- Manufacturer part number: 23004-AN001.
- Application: SR20DET.
- Engine designation: SR20DET.
- Bore / pin-size designation: φ22 Pin.
Application-specific requirements
- Users can select between φ86.5 (STEP1) and φ87.0 (STEP2) for condition of cylinder block or required specification of the engine.
- (Same for other engine models.)In case bore is not accurate circle, pistons cannot be installed accurately.
Installation and selection
Confirm the intended crankshaft and piston combination. Check bearing clearances, fastener procedure and rotating-assembly clearance during assembly.
