Description
Bilstein B8 6112 Suspension Kit – 2019–2023 Ford Ranger is an application-specific Bilstein suspension solution for Ford Ranger 2019-2023. For this application, the goal is to improve or restore suspension control while keeping the damper choice appropriate for the vehicle's ride height, spring package and intended use.
Why Bilstein B8 6112 for This Application?
B8 6112 is a front suspension system built around a larger monotube damper and matched coil spring. Compared with a basic replacement shock, the package is intended to provide greater damping capacity and ride-height setup flexibility for trucks and SUVs that see larger tires, added load or rough-road use. For the Ford application shown here, Bilstein assigns this product to Front, so the part should be chosen by both chassis fitment and suspension position.
Application-Specific Product Details
- Bilstein Series: B8 6112
- Product Type:
- Application: Ford Ranger 2019-2023
- Position: Front
- Listed Shipping Weight: 45.61 lb
- Country of Origin: US
Choosing the Right Bilstein Setup
For this application, the goal is to improve or restore suspension control while keeping the damper choice appropriate for the vehicle's ride height, spring package and intended use. If the vehicle has been lowered, lifted, converted from factory electronic suspension, or carries substantial added weight, verify that this exact Bilstein series and part number matches that configuration before purchase.
Bilstein Application Notes
- Front Lift Height: 0-2.9"
Part Numbers & Configurations
| Position / Configuration | Bilstein MPN | Listed Package Dimensions |
|---|---|---|
| Front | 47-294301 | L: 28 in; W: 12.75 in; H: 4.63 in |
Each selectable variant corresponds to the Bilstein part number shown above. Order the quantity required for the positions being serviced.
