Description
Action Clutch 7.25-inch Triple Disc Race Clutch Kit with Flywheel is a competition clutch assembly intended for dedicated race vehicles rather than daily street use.
Listed application: 2004–2021 Subaru WRX STi.
Torque Capacity and Technical Specifications
- Torque capacity: contact Legacy Racing to confirm the rating for this exact part before ordering. Match it against engine torque and intended use.
- Listed SFI specification: 1.2.
Construction and Performance
The assembly uses three 7.25-inch sintered-metallic race discs, a high-strength steel pressure plate and floater plates. A ventilated billet-aluminum clutch cover completes the multi-disc arrangement.
Driving Characteristics and Build Suitability
Multiple friction interfaces support competition holding capability, but disc count alone does not establish an application-specific torque rating. Race-oriented engagement and repeated street takeoffs should be considered before selecting this assembly.
Included Components
- Three (3) 7.25in American Sintered Metallic Race Discs
- One (1) High Strength Steel Alloy Pressure Plate
- Two (2) High Strength Steel Alloy Floater Plates
- One Piece Ventilated T6061 Billet Aluminum Clutch Cover
- Application-specific flywheel (material requires confirmation)
- Pilot Bearing / Bushing (when applicable)
- Clutch Alignment Tool
- Hydraulic Release Bearing
Installation and Selection Notes
- Push Type Conversion. Includes Hydraulic Release Bearing
- Push-type conversion application: confirm the required release mechanism, actuation components and installation hardware. Do not assume every conversion component is included.
- Confirm the included flywheel material and clutch pairing before ordering.
- Match the clutch to engine torque, intended use and future modifications. A published capacity alone does not establish suitability for repeated launches or sustained competition.
Break-in Requirements
Complete 100 street miles below 4,500 rpm, using no more than half throttle and avoiding boost where applicable. Use normal engagement cycles rather than accumulating highway mileage alone. Complete the prescribed break-in before performance use. If the vehicle cannot be street-driven, confirm an appropriate procedure for its intended competition use.
Vehicle Fitment
| Year | Make | Model | Submodel |
|---|---|---|---|
| 2004-2014 | Subaru | Impreza | WRX STI |
| 2015-2021 | Subaru | WRX STI | Base |
| 2015 | Subaru | WRX STI | Launch Edition |
| 2015-2021 | Subaru | WRX STI | Limited |
| 2019 | Subaru | WRX STI | S209 |
| 2016 | Subaru | WRX STI | Series.HyperBlue |
| 2018 | Subaru | WRX STI | Type RA |
Manufacturer part number: ACR-2306-3D. Legacy Racing SKU: AONACR-2306-3D.
